Features:
- Bushing Options:
Choices of the Porcelain or Epoxy Resin (EMC) Type. - Super-Fast Switching Speed:
Embedded unique Solenoid Drive technology – Switching
in just 0.13 seconds - Embedded Current (CT) Sensor:
CT Sensor is available upon request. - In Respect to Polluted Condition:
Up to Very Heavy Pollution level. - Switchgear Enclosure:
Stainless Steel. - Optional Surge Arrester is available
Ratings:
- Rated Voltage: 24kV / 36kV
- Rated Current: 630A
- Rated Making Current (peak): 40kA / 33kA
- Lightning Impulse Withstand (BIL): 150kV / 170kV
- Rated Short Time Current (1s): 16kA / 13kA
